Using the SOT-227 package, Ohmite's TGHD series features flat type, 100 W high power resistors that require an air-cooled heatsink or water cooling to reach peak performance. These resistors are offered either with quick connect tabs or flywire leads. The TGHDX series with the flywire leads is a true SOT-227, the TGHDV series is a mini SOT-227. The TGHD series is a great option for applications such as harmonic filters, surge protection, dummy loads, high-frequency amplifiers, and many more.
Features
- #187 quick connect tabs or flywire leads
- Flat type, 100 W high power resistor
- Air-cooled heat sink or water cooling required
- Higher density packing, vibration-proof, insulation withstand voltage, and perfect heat dissipation possible
- TGHDX with wire leads follows the popular SOT-227 land pattern, TGHDV is a mini SOT-227
Applications
- Harmonic filters
- Snubber resistors
- Surge protection
- Breeder resistors
- Dummy loads
- Gate resistors
- Dumping resistors for automotive electronics
- Power supplies
- High-frequency amplifiers
