The AD-SYNCHRONA14-EBZ is an ideal self-contained device to use in evaluation and prototyping of applications that need a highly accurate frequency and phase-controlled source clock. It is designed around the Analog Devices AD9545 and HMC7044 and greatly simplifies clock distribution and multi-channel synchronization in complex systems.
The AD-SYNCHRONA14-EBZ is an ideal self-contained device to use in evaluation and prototyping of applications that need a highly accurate frequency and phase-controlled source clock. It is designed around the Analog Devices AD9545 and HMC7044 and
greatly simplifies clock distribution and multi-channel synchronization in complex systems.
The AD-SYNCHRONA14-EBZ is intended to be used by trained professionals in a laboratory environment, and not intended as an end product
for commercial use. It can be taken as a complete reference design and customised as required for any end customer applications. Full design details are made available free of charge.
The device comes in a 1U mechanical form factor and uses
industry-standard SMA and TwinAX connectors that are commonly found in labs. Its applications include:
- High accuracy reference clock distribution
- Systems clocked from a single source
- Clocks derived from 100MHz or 122.88MHz
- Phased Array Systems, RADAR, EW, SATCOMS, SDR
- Bench Equipment
- Remote controlled operation
Analog Devices’ evaluation board can be purchased from element14 in APAC.
